Leeb Hardness Tester Meter Gauge 170～960 HLD Cast Iron Thermal Printer

Leeb Hardness Tester Meter Gauge 170–960 HLD Cast Iron with Thermal Printer

This advanced Leeb hardness tester is designed to measure the hardness of metallic materials, offering precise results across a wide range. Its large dot matrix LCD screen displays all functions and parameters clearly, making it user-friendly for both experienced and novice users. The integrated high-speed thermal printer provides instant documentation of measurement results.

Features:

• Large screen (128×64 dot matrix LCD) displaying all functions and parameters
• Allows testing at any angle, even upside down
• Wide measuring range, capable of measuring the hardness of all metallic materials with direct display of hardness scales: HRB, HRC, HV, HB, HS, HL, and three types of strength values
• Compatible with seven impact devices for special applications
• Large memory capacity storing up to 500 groups of information, including single measured values, mean values, testing data, impact direction, impact times, material type, and hardness scale
• Preset upper and lower limits with automatic alarms for out-of-range results
• Battery information indicator showing charge status
• User calibration function for personalized settings
• USB port with multi-functional data processing software for PC connectivity
• Integrated high-speed thermal printer for on-site results
• Powered by a rechargeable Ni-MH battery with a charge circuit integrated inside the instrument, allowing a continuous working period of no less than 150 hours (with backlight off and no printing)
• Auto power-off feature to conserve energy

Applications:

• Testing the hardness of metallic structures and materials, molds, bearings, heavy workpieces, and installed machinery
• Failure analysis of pressure vessels, steam generators, pipework, and other equipment
• Material identification in warehouses
• Rapid testing over a large hardness range

Technical Specifications:
