EMF ELF Magnetic Field Gauss Meter (30~300Hz) TAIWAN MADE

EMF ELF Magnetic Field Gauss Meter (30~300Hz) TAIWAN MADE

This EMF/ELF Meter (Gauss Meter) is designed to measure the electromagnetic field of extremely low frequency (ELF) ranging from 30Hz to 300Hz. The readings can be displayed in milliGauss (mG) or microTesla (µT), which can be switched anytime by simply pressing a button.

Equipped with a Hold function, it can display the maximum reading (Max) as well. This meter is highly sensitive, with a wide measurement range up to 2000mG/200µT. The accuracy is within ±(2.5% + 6 digits) at 50/60Hz.

Understanding Electromagnetic Waves:

The interaction of electric fields generates magnetic fields, and the fluctuations between the two are known as electromagnetic waves. This form of energy, similar to light and heat, can be transmitted through radiation in the air or via electrical conductors. To minimize prolonged exposure to excessive electromagnetic fields, it is recommended to rearrange environments, especially in homes and workplaces where strong electromagnetic fields are detected.

EMF measurements have become increasingly important in various sectors to assess environmental and human exposures to non-ionizing radiation.

Applications:

This meter is ideal for measuring electromagnetic fields of extremely low frequency (ELF) from 30 to 300 Hz. It can accurately gauge the electromagnetic field radiation intensity produced by electric transmission equipment, power lines, microwave ovens, air conditioners, refrigerators, computer monitors, and audio/video devices, among others.

Features:

• 30 ~ 300 Hz measurement range
• MADE IN TAIWAN
• Selectable Micro-Tesla or Milli-Gauss readings
• Data hold (HOLD) and maximum (MAX) hold functions
• Range display options: 20/200/2000
• Low battery indicator
• Overload indicator (“OL”)

Specifications:

• Display: 3-1/2 digits LCD with 1999 maximum reading
• Measuring Range: 200/2000 mG, 20/200 µT
• Resolution: 0.1/1 mG or 0.01/0.1 µT
• Frequency Response: 30Hz to 300Hz
• Sensor: Single Axis
• Accuracy: ±(2.5% + 6 digits) at 50Hz/60Hz
• Sample Rate: 2.5 times per second
• Overload: LCD displays “OL”
• Power Supply: 1 x 9V Battery (included)
• Battery Life: Approximately 100 hours
• Operating Environment:
  • Temperature: 5 ~ 40°C
  • Humidity: < 80% RH
• Storage Environment:
  • Temperature: -10 ~ 60°C
  • Humidity: < 70% RH
• Weight: About 170g
• Dimensions: 130 x 56 x 38mm
