Digital Belt Tension Meter Gauge (kg, lb, Newtons)

The Belt Tension Tester is designed for precise measurement of belt tension and is also versatile enough to measure the tension of tapes, wires, and other objects. Ideal for use in industries such as automotive, textile, cables, plastic films, paper, and printing, this tester is both lightweight and rugged, ensuring durability and ease of use.

Features

• Utilizes a Micro-computer LSI circuit and crystal time base for high accuracy measurements
• Measures and adjusts tension for timing and auxiliary belts in motor vehicles and machinery
• Displays tension in various standard and manufacturer-specific units
• Allows manual or automatic setting of tension limits
• Remembers selected tension limits, units, and calibration parameters even when switched off
• USB data output for PC connection (cable and software not included)
• Bluetooth data output option (adapter and software not included)
• Auto power off after 10 minutes of inactivity
• Low battery indication

Specifications

• Display: 4 digits, 10mm LCD
• Tension Indicator: Colored LED indication for High, Low, and OK
• Measurement Range:
  • 0~750 N (Newtons)
  • 0~120 lb (Pounds)
  • 0~77 kg (Kilograms)
  • 0~114 Seems
• Belt Width: Up to 36 mm
• Overload Alarm: 750N (Adjustable)
• Maximum Load: 850N
• Resolution: ±1 (Least Significant Digit of Units)
• Accuracy: ±5% of full-scale
• Data Output: USB, RS-232, Bluetooth (software, cable, and adapter not included)
• Audible Warning: Piezoelectric sounder
• Power Supply: 4 x 1.5V AAA (UM-4) battery
• Battery Life: Approximately 100 hours of continuous operation
• Dimensions: 135 x 62 x 33 mm
• Weight: 335g (excluding batteries)
